Network

Technology

GSM / CDMA / HSPA / EVDO / LTE / 5G

Launch

Announced

2022, January 04

Status

Available. Released 2022, January 07

Body

Dimensions

155.7 x 74.5 x 7.9 mm (6.13 x 2.93 x 0.31 in)

Weight

177 g (6.24 oz)

Build

Glass front (Gorilla Glass Victus), plastic back, aluminum frame

SIM

Single SIM (Nano-SIM)

IP68 dust/water resistant (up to 1.5m for 30 min)

Display

Type

Dynamic AMOLED 2X, 120Hz, HDR10+

Size

6.4 inches, 100.5 cm2 (~86.7% screen-to-body ratio)

Resolution

1080 x 2340 pixels, 19.5:9 ratio (~403 ppi density)

Protection

Corning Gorilla Glass Victus

Always-on display

Platform

OS

Android 12, up to 4 major Android upgrades, One UI 6.1

Chipset

Qualcomm SM8350 Snapdragon 888 5G (5 nm) – Version 1

CPU

Octa-core (1×2.84 GHz Cortex-X1 & 3×2.42 GHz Cortex-A78 & 4×1.80 GHz Cortex-A55) – Version 1

GPU

Adreno 660 – Version 1

Mali-G78 MP14 – Version 2

Memory

Card slot

No

Internal

128GB 6GB RAM, 128GB 8GB RAM, 256GB 6GB RAM, 256GB 8GB RAM

UFS 3.1

Main Camera

Triple

12 MP, f/1.8, 26mm (wide), 1/1.76″, 1.8µm, dual pixel PDAF, OIS

8 MP, f/2.4, 76mm (telephoto), 1/4.5″, 1.0µm, PDAF, OIS, 3x optical zoom

12 MP, f/2.2, 13mm, 123˚ (ultrawide), 1/3.0″, 1.12µm

Features

LED flash, auto-HDR, panorama

Video

4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, gyro-EIS

Selfie camera

Single

32 MP, f/2.2, 26mm (wide), 1/2.74″, 0.8µm

Features

HDR

Video

4K@30/60fps, 1080p@30/60fps, gyro-EIS

Sound

Loudspeaker

Yes, with stereo speakers

3.5mm jack

No

32-bit/384kHz audio

Comms

WLAN

Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct

Bluetooth

5.0, A2DP, LE

Positioning

GPS, GLONASS, BDS, GALILEO

NFC

Yes

Radio

Unspecified

USB

USB Type-C, OTG

Features

Sensors

Fingerprint (under display, optical), accelerometer, gyro, proximity, compass

Samsung DeX (desktop experience support)

Circle to Search

Battery

Type

Li-Ion 4500 mAh, non-removable

Charging

25W wired, PD3.0, 50% in 30 min (advertised)

15W wireless

Reverse wireless

Misc

Colors

Graphite

Models

SM-G990U1

SAR

0.77 W/lb (head)     0.90 W/lb (body)

SAR EU

0.95 W/lb (head)     1.48 W/lb (body)

Tests

Performance

AnTuTu: 566529 (v8), 719696 (v9)

GeekBench: 3049 (v5.1)

GFXBench: 56fps (ES 3.1 onscreen)

Display

792 nits max brightness (measured)

Camera

Photo / Video

Loudspeaker

-26.9 LUFS (Good)

Battery (old)

Endurance rating 92h
